Domane AL 2 Gen 4

KHUNG XE

100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, flat-mount disc, 142×12 mm thru axle

PHUỘC

Domane AL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12×100 mm thru axle

ĐÙM TRƯỚC

Formula RX-512 alloy, 6-bolt, 100×12 mm thru axle

KHOÁ ĐÙM TRƯỚC

Bontrager Switch chamfered thru axle, removable lever

ĐÙM SAU

Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142×12 mm thru axle

KHOÁ ĐÙM SAU

Bontrager Switch chamfered thru axle, removable lever

VÀNH XE

Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve

CĂM XE

14 g stainless steel, black

VỎ XE

Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700×32 mm

CỠ VỎ TỐI ĐA

38mm without mudguards, 35mm with mudguards

TAY ĐỀ

Shimano Claris ST-R2000-R, 8 speed

ĐỀ TRƯỚC

Shimano Claris R2000, 31.8 mm clamp

ĐỀ SAU

Shimano Claris R2000, medium cage, 34T max cog

GIÒ ĐẠP

Size: 44 – Shimano RS200, 50/34 (compact), 165 mm length | Size: 49, 52, 54 – Shimano RS200, 50/34 (compact), 170 mm length | Size: 56, 58, 61 –Shimano RS200, 50/34 (compact), 175 mm length

TRỤC GIỮA

Shimano UN300, 68 mm, threaded cartridge, 110 mm spindle

Ổ LÍP

Shimano HG31, CS-HG31, 11-32, 8 speed

SÊN XE

SShimano Sora HG71, 8 speed

BÀN ĐẠP

N/A

YÊN XE

Verse Short, steel rails, 145 mm width

CỐT YÊN

Size: 44, 49 – Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length | Size: 52, 54, 56, 58, 61 –Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length

TAY LÁI

Size: 44, 49 – Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 38 cm width | Size: 52 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width | Size: 54, 56 –Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width | Size: 58, 61 –Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 44 cm control width, 48 cm drops width

DÂY QUẤN

Bontrager Supertack Perf tape

CỔ LÁI

Size: 44 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length | Size: 49 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length | Size: 52, 54 –Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length | Size: 56, 58 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length | Size: 61 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length

BỘ CHÉN CỔ

FSA Integrated, sealed cartridge bearing, 1-1/8″ top, 1.5″ bottom

THẮNG XE

Tektro C550 mechanical disc brake, dual piston, flat mount

ROTOR THẮNG

Tektro wave, 6-bolt, 160 mm

TRỌNG LƯỢNG

56 – 10.55 kg / 23.26 lbs

LƯU Ý

Tối đa 125kg bao gồm người lái, khung và đồ đạc trên xe
